The ideal solution for finishing the molds, the D321 combines a compact size with considerable operating volume. The large glazed front door facilitates the access of large molds and equipment, providing excellent visibility during processing. Fast and precise, the D321 is equipped with the M5A head. This head is efficient and suitable for a wide range of materials, from steel to aluminum to composites.
Find Out More : D 321
The new line of Gantry GTF machines is characterized by its great strength. Thanks to the combination of components selected according to weight, stiffness, costs, with a true modular construction, the GTF series becomes the ideal solution to satisfy the most demanding customers.
The K series is a line of high speed 5-axis milling machines specifically designed for the processing of large plastic injection molds and structural components for the aerospace industry. The fixed bench structure of the machine guarantees maximum precision and optimal supervision of all processes.
This is the line of high speed milling machines Fidia specifically designed for finishing surfaces with 3 + 2 and 5 continuous axes. The use of spindles dedicated to this application, with a high number of revolutions, guarantees excellent surface quality results.
Find Out More : D 218 / 318 / 418
G996 is the high speed milling / milling milling center, featuring a highly compact high gantry structure. Its impressive and sturdy monolithic structure allows the complete processing of small-medium sized parts of any material, even the most tenacious.
Find Out More : G 996
It is the high speed milling center suitable for processing small parts. Find application in the processing of dowels, molds for forging, models, electrodes, as well as small series production.
Find Out More : HS664
The recent request to increase the level of automation, by integrating the same palletizing system for different machines, has led Fidia to design a new FMS with related production flow optimization software.
Find Out More : FMS
With the nC19 Fidia has created a compact and efficient control, characterized by optimized electronics and suitable for modern machine tools.
Find Out More : nC19: compact and functional
Characterized by a linear and compact design, the C20 numerical control is used on high performance 3 and 5 axis milling machines.
Find Out More : C20: high performance
The Fidia C40 Vision CNC is a very powerful control, suitable for the most complex applications and for high-speed machining in the aerospace, automotive and energy industries. The multiprocessor architecture allows the use of the most advanced features developed by Fidia to improve efficiency and safety on the machine.
Find Out More : C40 Vision: speed, precision, safety
The M5A is a continuous bi-rotary head ideal for executing the complete machining cycle, from roughing to finishing.
Made of aluminum alloy, the M5C head is the "light" version of the M5A. It is an asymmetrical birotative head for light alloys and 35kW finishing.
The M5D bi-rotary head offers an extraordinary volume of chip removal on aluminum, making the production of large aeronautical structural parts very efficient.
Find Out More : M5D: Bi-rotary Head, spindle power 100 KW
At the same time, M5E offers high roughing capacity and high finishing speeds on steel, cast iron and tough materials.
The M5H head with mechanical transmission spindle develops a high torque and integrates an automatic change of accessories that facilitate access in the narrowest cavities.
The M5S head body is made of cast iron and its symmetrical fork structure optimizes thermal stability.
Find Out More : M5S: Symmetrical Birotative head for aeronautical machining
The MBSH indexed bi-rotary head has been designed to equip medium-sized machines with a swivel spindle with high removal capacity and high rpm.
Find Out More : MBSH / 55: Indexed Bi-rotary Head, spindle power 55 KW
Head Calibration Device
The HMS is a device for measuring and compensating geometric errors of a continuous or indexed bi-rotary head or a rotary-tilting table. Improves the precision and quality of machining on 5-axis machines, without requiring complex interventions by specialized technicians.
Find Out More : HMS: for the compensation of geometric errors
Tool Measuring By Laser
The TMSC device consists of a focused laser beam applied on a special base to be installed on the machine and is used to measure the length and diameter of the mounted tool and to verify its shape. The measurement is performed with the rotating tool. The measuring cycles are provided for 10 different types of tools (spherical, toric, conical, etc.).
Find Out More : TMSC: Device for measuring tools
The K5 probe, combined with the specific software for the entire Fidia control range, is used to continuously survey three-dimensional surfaces. The stored data can be used as a machining path or transferred to CAD / CAM systems for further processing.
Find Out More : K5: Probe for continuous scans
Remote Hand Pendent
The Fidia portable push button panel replicate the most used commands of the main panel. Especially useful on large machines, they allow the machine to be controlled from an easier position and to control the processing more closely.
XPower Digital Drives
The Fidia XPOWER series digital drives have been designed for the movement of axes and spindles. Suitable to be mounted on a wide range of machine tools, they can control brushless, linear or torque axes and asynchronous and synchronous spindles.
Find Out More : XPower: digital drives
I / O LINE Modules
Fidia I / O Line ™ is the new generation of Fidia input / output modules, intended to be installed in the electrical panel of the machine tool and connected to the control via the Fidia FFB fieldbus.
Find Out More : LINE I / O modules
i-Prevent is a utility software tool, which reminds you for timely preventive maintenance and provides step by step assistance.
Find Out More : i-Prevent
This software tool is integrated with Fidia CNC to provide quick help for Aucol PLC alarms that enables you to troubleshoot problems.
Find Out More : i-Help
In order to monitor the activities performed on the machines, from milling times to downtime and breakdowns, Fidia has developed the HiMonitor module, which provides this information both on the control itself and on a remote device, such as a smartphone, tablet or PC.
Find Out More : HiMonitor: Monitoring system
The innovative user interface allows the definition of profiles with the simple use of soft-keys and mouse. This results in an immediate and easy interaction even for operators who do not have specific programming knowledge. The package includes a wide range of fixed drilling cycles and complex cycles for processing pockets of any profile.
Find Out More : Isograph: 2D CAD / CAM for on-board programming
With Velocity 5™, Fidia introduces a new technique for axis control that significantly improves the performance of the milling machine, both in 3-axis and 5-axis machining.
Find Out More : Velocity 5 ™: Quality & High Speed
ViMill is an anti-collision system that works on the machine. Being fully integrated on the Fidia numerical control, ViMill is always active during all the phases of use of the machine, either by program or by moving the axes from the pushbutton panel or the handwheel.
Find Out More : ViMill: Anti-collision system
The Fidia CNC foresees that a sequence of operations can be stored in a PRC "Procedure" and then performed automatically. This solution allows the execution of a series of unattended processes and increases operational safety in the case of repetitive operations. For more demanding automation needs, the PRX programming language is available, which extends the use of procedures to even the most complex cases.
Find Out More : PRC-PRX: Customized automation
